  oly_35_rc_front_lens_1.jpg - Start off by unscrewing the outermost, thin retaining ring. Normal thread, open counter-clockwise. Then, lift out the nameplate, along with the ASA selector and CdS cell. Mine was a little stuck, since there was (no longer is, straightened out now) a little dent on the filter ring. I like to work on top of soft leatherette to make sure the camera isn't scratched in the process.
oly_35_rc_front_lens_2
oly_35_rc_front_lens_3
oly_35_rc_front_lens_4
oly_35_rc_front_lens_5
oly_35_rc_front_lens_6

Start off by unscrewing the outermost, thin retaining ring. Normal thread, open counter-clockwise. Then, lift out the nameplate, along with the ASA selector and CdS cell. Mine was a little stuck, since there was (no longer is, straightened out now) a little dent on the filter ring. I like to work on top of soft leatherette to make sure the camera isn't scratched in the process.
